ZAPCO Class AB Full-Range Mono Amplifier

ZAPCO Class AB Full-Range Mono Amplifier

• Features and Functions
  •Class-AB, Full-Range Mono Amplifier
  •Signal to noise ratio of over 110dB
  •Coupled the output drivers
  •Highest HFE (Gain) Sanken selected output devices
  •Differential balanced input stage
  •0.1% resistors for lowest possible noise floor
  •TI LME49720 (BJT) op-amps on the inputs
  •TI LME49720 (BJT) op-amps in the signal path
  •WIMA MKS2 series caps in the signal path
  •Extremely low ESR caps throughout
  •Proprietary patented RCA connectors
  Specifications
  •Power @ 4Ω: 1000 watts
  •Power @ 2Ω: 2000 watts
  •THD @ Rated Power < 0.05%
  •Signal to Noise Ratio > 110dB
  •Frequency Response 10Hz to 30,000Hz ±1dB
  •Input Sensitivity 1v to 9v
  •Dimensions in mm: 190(W) x 62(H) x 482(L) Overall: 190(W) x 62(H) x 518(L)
